Key features

Sheet width range : 600 – 800 mm
Forming area : 750 x 450 mm
Sheet thickness : 0.3 to 2 mm
Minimum product weight : 1.4 gms
Max. mechanical speed : 40 cycles/ min

Salient Features
Versatile machine for PP / PS / PET thermoforming
Servo driven sheet transport assembly with preheating arrangement
Heating tray with infrared ceramic heaters mounted with specially designed reflectors
Servo Drive robust tilting style forming station
Indigenously designed and Manufactured mould with quick product cooling
Automatic stacker for drinking glass og 1.4 gms
Automatic glass counting and packing unit
Unwinding station with pneumatic roll loading system
Online skeleton winder with motorized adjustment
Automatic lubricating system
Touch screen control panel

Varieties of plastic glass for
